Our Specialties

  • Plastic Part Design (injection mold, vac form, extrude, blow mold, silicone keypads)

    • Including assistance in sourcing tooling & molding

  • Class-A Surfacing

  • Electronics Packaging

    • PCB mechanical definition
    • Switches (types, forces)
    • User interface of components (connectors, switches, plugs, etc.)
    • Keypads (polycarbonate, tactile, silicone)

  • Assembly & Detail Drawings

Agency Work

UL

  • 94 flammability
  • Material specification (indoor/outdoor, f1-f2, UV)
  • Electronic device spacing requirements (hi & low voltage separation)

Our Services

3D Mechanical Design Engineering Utilizing Creo and Solidworks

Complex Surfacing and Assemblies

Sheetmetal

Drawings (to ASME-Y14.5M standards)

Packaging Studies

Simple Fixture Design

Plastic Part Design (an Orrbit Design specialty)

Project Management

Prototyping

  • Urethane Castings
  • CNC machining (steel, aluminum, plastic, foam, etc.)
  • Finish Work (hand crafting, painting, etc.)
  • Soft tooling

Analysis

  • Mechanica, static only (structure & thermal)
    • Mechanicais a module of Creo, used for quick analytical review of parts
  • Ansys, full dynamic linear & non-linear FEA, CFD & Thermal  | See “NEW FOR 2020” below

New For 2020

FEA, CFD & Thermal Analysis

Partnership for high level Analysis capabilities & CAD (solids & surfacing)

Mark Kramer

  • BSME & BS Product Design & Mfg
  • Masters, BioMedicalEng
  • Graduate classes in FEA & CFD
  • Over 10yrs experience in FEA

Software:

  • Creo & Solidworks: Solid modeling, surfacing in both

  • Ansys: Full suite of options, Full non-linear FEA & CFD

Engineering Intern Training–

 …for the simpler things in life

  • Trained in Creo & Solidworkssolid modeling, assemblies & drawing creation

  • Currently training for surfacing work

Orrbit has developed other engineering contacts available for additional CAD and ME work upon request & scheduling- let us know what you need.
